A roof-mounted condensing unit connects via pipeline and flare connections to service valves, routing refrigerant through a wall sleeve with a wall cap into the interior space. The interior wall-mounted unit provides conditioned air flow and connects to a condensate pump and drain line at the ceiling level.
ROOF CONDENSING UNIT AIR FLOW PIPE LINE DRAIN LINE WALL CAP WALL SLEEVE FLARE CONNECTION TO SERVICE VALVES CEILING CONDENSATE PUMP 5 WALL MOUNT DUCTLESS SYSTEM
