The unit heater is suspended from a two-inch by two-inch by one-quarter-inch welded steel angle bracket that is secured to the wall with concrete anchors. Two three-eighths-inch diameter steel rods with turnbuckles provide vertical support for the heater, maintaining a minimum clearance of one foot. Lateral stability is provided by one-eighth-inch diameter cables at each corner, installed at a forty-five-degree angle. The assembly requires coordination with structural plans for final attachment to the building structure.
