Mechanical · M-F837J

Chiller Piping Detail

Materials

Elements

Drainage Connections / Plates Reinforcing

About this detail

Piping connections and valve arrangements serve a chiller mounted on a nominal three-and-a-half-inch concrete pad. Two-inch and smaller lines utilize ball valves, while two-and-a-half-inch and larger lines incorporate butterfly valves. Flanged, grooved, or threaded connections tie into the system alongside digital thermometers and half-inch test ports. A three-quarter-inch drain ball valve with a capped hose end connection is provided, and pipe supports are installed as required with adequate service clearances. Refrigerant relief lines run to the building exterior for indoor chillers, and control drawings govern the locations of temperature sensors and flow switches.
