A ceiling grille connects to a supply or return duct through a flexible duct run limited to a maximum length of five feet. The flexible duct attaches using a drawband with sealant or UL-approved tape, or a factory metal collar screwed to the duct or register collar and sealed with UL-approved tape or duct sealant. A manufacturer-installed balance damper or flag damper with a ribbon is included where applicable. Hangers installed per SMACNA standards secure the ductwork to the structure above. For T-bar ceiling applications, diffusers are positively attached using lay-in support clips or by mechanical fastening to the T-bar runner.
MANUFACTURER INSTALLED BALANCE DAMPER, WHERE APPLICABLE FLAG DAMPER WITH RIBBON DRAWBAND WITH SEALANT OR UL APPROVED TAPE; OR FACTORY METAL COLLAR SCREWED TO DUCT OR REGISTER COLLAR AND SEALED WITH UL APPROVED TAPE OR DUCT SEALANT (TYP.) CEILING GRILLE TO STRUCTURE ABOVE TO STRUCTURE ABOVE FLEX DUCT WHERE INDICATED ON PLANS (5'-0" LONG MAX) HANGER PER SMACNA NECK SIZE VARIES DETAIL NOTES: FOR T-BAR CEILING APPLICATIONS, DIFFUSERS SHALL BE POSITIVELY ATTACHED BY: 1a) LAY IN SUPPORT CLIP OR 1b) MECHANICALLY FASTENED TO T-BAR RUNNER CEILING
