Steel angle connections frame into a structural channel and a wide flange steel beam sized per plan. A steel plate measuring one-quarter inch by three and one-half inches by three and one-half inches is welded to the channel using three-sixteenths inch fillet welds and connects with one three-quarter inch diameter ASTM A325-N bolt. A second assembly utilizes a steel plate measuring one-quarter inch by four inches by four inches welded to the beam web with three-sixteenths inch fillet welds and secured with one three-quarter inch diameter ASTM A325-N bolt. Both configurations maintain a one-half inch maximum clearance gap with edge distances dimensioned at one and one-half inches.
1/2" MAX 1/2" 1 1/2" 1 1/2" 1 1/2" MAX 1/2" 1 1/2" 1 1/2" ANGLE TO CHANNEL ANGLE TO BM STL BM PER PLAN STL ANGLE PER PLAN 3/16 3/16 STL CHANNEL PER PLAN STL PL: 1/4"x3 1/2"x3 1/2" W/ (1) 3/4"Ø A325'N 3/16 3/16 STL PL 1/4"x4"x4" W/(1) 3/4"Ø A325N
