A transverse and longitudinal four-way cable brace for ceiling-hung equipment, featuring support members and support rods equipped with rod stiffeners. Diagonal cable braces run at angles between thirty and ninety degrees relative to the structure, connecting to the braced components. Additional plan view layout details show the directional positioning of the transverse and longitudinal cable braces around the suspended equipment unit.
TRANSVERSE and LONGITUDINAL (4-WAY) BRACE FOR CEILING HUNG EQUIPMENT PLAN VIEW CEILING HUNG EQUIPMENT CEILING HUNG EQUIPMENT SUPPORT ROD (SHOWN) WITH ROD STIFFENER. SEE ROD 45° REQUIREMENTS. STIFFENER DETAILS FOR TRANSVERSE & LONGITUDINAL (TYP.) CABLE BRACE SUPPORT MEMBER SUPPORT MEMBER 30° - 90° SEE DETAILS OF TYPICAL CABLE CONNECTIONS TO SEE DETAILS OF TYPICAL CABLE CONNECTIONS TO BRACED COMPONENTS STRUCTURE Jo[3 1o[3
