M-DWEF3 — Mechanical Equipment Seismic Restraint Snubber Connection

Mechanical · M-DWEF3

Mechanical Equipment Seismic Restraint Snubber Connection

Materials

Elements

Anchors / Embeds

Connections

Welded Connection

About this detail

An equipment frame connects to a specified snubber assembly anchored to a concrete substrate. A welded jam nut secures the framing connection with specified expansion anchors installed per the manufacturer's recommendations.

EQUIPMENT FRAME (TYP) JAM NUT (WELDED) DETAIL B - SEISMIC RESTRAINT SPECIFIED SNUBBER. CONCRETE EXPANSION ANCHOR NUMBER AND SIZE PER THE MANUFACTURER'S RECOMMENDATIONS. ELEVATION 1/4 1/4

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
