Pipes penetrate through the roof deck assembly protected by a sheet metal hood and a flexible or sheet metal tube collar. Base flashing is secured with nominal fasteners spaced approximately eight inches on center, while base flashing fasteners are spaced approximately twenty-four inches on center. Pipes slope away from the hood to prevent water accumulation. The interior of the metalwork is insulated in cold climates.
IN COLD CLIMATES 2" NOMINAL FASTNERS APPROX. 8" O.C. BASE FLASHING FASTNERS APPROX. 24" O.C. SLOPE PIPES AWAY FROM HOOD TUBE COLLAR SHEETMETAL OR FLEX SHEETMETAL HOOD INSULATE INSIDE OF METALWORK
