The condensing unit is mounted on a level base over the roof structure and secured with angle iron brackets attached to the unit base. Liquid and suction refrigerant connections are provided on the side panel with sizing per the equipment chart. The unit rests on a leveled support assembly positioned directly on the roof.
ATTACH UNIT TO BASE ANGLE IRON BRACKET CONDENSING UNIT (SEE CHART RO SIZE). LIQUID CONNECTION SUCTION CONNECTION (SEE CHART FOR SIZE). LEVEL BASE ROOF 6 CONDENSING UNIT ON ROOF 2
