An in-line pump is suspended below a structural wide flange beam using a beam clamp supplied by the mechanical contractor. A threaded rod extends downward from the beam clamp through a spring isolator sized and installed by the mechanical contractor. The threaded rod connects to a C channel support located beneath the pump assembly. A minimum three-quarter-inch thick rubber isolation pad is mounted below the pump against the C channel support. Water piping connects to both sides of the inline pump.
INLINE PUMP 'C' CHANNEL SUPPORT THREADED ROD WATER PIPING WATER PIPING SPRING ISOLATOR SIZED & INSTALLED BEAM CLAMP WIDE FLANGE BEAM BY STRUCTURAL MIN. 3/4" THICK RUBBER ISOLATION PAD MOUNTED BELOW PUMP BY MECHANICAL CONTRACTOR BY MECHANICAL CONTRACTOR BY MECHANICAL CONTRACTOR BY MECHANICAL CONTRACTOR BY MECHANICAL CONTRACTOR
