A sidewall supply register and fire damper connect to the wall framing using code-gauge mounting angles and fasteners. A code-gauge sleeve houses the damper assembly, with the damper actuator mounted outside the airstream. The duct connects to the sleeve using a hemmed S-slip connection or a Ductmate breakaway connection, sealed airtight. An access panel is provided on the ductwork for maintenance.
CODE CLEARANCE SIDEWALL SUPPLY REGISTER FIRE AND DAMPER ATTACH REGISTER TO WALL FRAMING. HEMMED "S" SLIP DUCT CONNECTION OR DUCTMATE BREAKAWAY CONNECTION; SEAL AIRTIGHT DAMPER ACTUATOR MOUNT OUTSIDE OF AIRSTREAM. CODE GAUGE SLEEVE MOUNTING ANGLES ACCESS PANEL
