The assembly features a combination smoke/fire damper housed inside a sleeve connected to duct break-away joints and sealed with caulking material. Mounting angles secure the damper frame to the rated ceiling system, while an actuator, over-center link, connecting rod, and flexible conduit provide mechanical operation. A grille or diffuser is positioned at the ceiling plane with an access door above.
Text on the drawing
MOUNTING ANGLES 1 1/2x 1 1/2x16 GAGE MIN. GRILLE/DIFFUSER RATED CEILING OVER-CENTER LINK ACTUATOR (LOCATION MAY VARY) DAMPER FRAME CAULKING MATERIAL JOINT, SLEEVE TO DUCT BREAK-AWAY CONNECTIONS CONNECTING ROD TS150 OR EFL OR PFL (LOCATION MAY VARY) UL LISTED 555 AND 555S COMBINATION SMOKE/FIRE DAMPER 16" MAX. FLEX CONDUIT ACCESS DOOR SLEEVE
