The wall cleanout comprises a plugged tee with a cleanout fitted within a wall assembly, finished with a chrome wall cover and screw, and connected to piping that may extend as a waste or vent. The floor cleanout features a cleanout and access cover set flush with the top of the floor line, connected via an eighth-bend cast iron balancing pipe.
WALL CLEANOUT FLOOR CLEANOUT CLEANOUT & ACCESS COVER TOP OF COVER TO BE FLUSH W/ TOP OF FLOOR FLOOR LINE 1/8" C.I. BEND BALANCE PIPING 1/8" C.I. BEND BALANCE PIPING FLOOR LINE PLUGGED TEE W/ CLEANOUT WALL CHROME WALLCOVER & SCREW MAY EXTEND AS A WASTE OR VENT M601 2 CLEANOUT DETAIL
