A pipe penetrates a fire-rated wall through a metal pipe sleeve set into the partition. The pipe is wrapped with fiberglass pipe insulation, transitioning to rockwool pipe insulation at the penetration for a distance of six inches on each side. Fireproof caulk is applied as a through-penetration firestop sealant on both sides of the wall between the sleeve and the insulated pipe.
FIRE RATED WALL PIPE SLEEVE PIPE FIBERGLASS PIPE INSULATION ROCKWOOL PIPE INSULATION THRU PENETRATION FIRE PROOF CAULK (TYP. FOR BOTH SIDES) 6" 6"
