This assembly provides transverse and longitudinal seismic restraint for piping supported by clevis hangers. The system utilizes wire rope or cable installed taut at angles between 30 and 90 degrees relative to the structure. A U-bolt with channel strut is installed on top of the pipe to prevent longitudinal sliding through the clevis hanger. The support rod includes a stiffener to meet specific seismic requirements. Cable connections to the structure and the braced components are referenced to separate typical detail sheets.
Text on the drawing
TRANSVERSE and LONGITUDINAL (4-WAY) BRACE PLAN VIEW OF BRACE FOR INSULATED or UNINSULATED PIPE ON CLEVIS TYPE HANGERS SLIDING THROUGH CLEVIS MEANS) TO PREVENT PIPE ON TOP OF PIPE (OR OTHER U-BOLT W/ CHANNEL STRUT 45° TRANSVERSE & LONGITUDINAL CABLE BRACE PIPE (TYP.) SEISMIC WIRE ROPE/CABLE BRACING STRUCTURE CABLE CONNECTIONS TO SEE DETAILS OF TYPICAL CLEVIS HANGER SEE DETAILS OF TYPICAL PIPE SLEEVE TAUGHT BRACED COMPONENTS CABLE CONNECTIONS TO CABLE INSTALLED 30° - 90° LISTED STIFFENER DETAILS FOR ROD STIFFENER. SEE ROD SUPPORT ROD (SHOWN) WITH REQUIREMENTS. PIPE R
