M-BAYBW — Rectangular Duct Fittings And Take-Off

Mechanical · M-BAYBW

Rectangular Duct Fittings And Take-Off

Units: imperial
Sheet: M-400
Discipline: Mechanical

Materials

Metal (misc.)Steel

Elements

Text on the drawing

SQUARE ELBOW NOTES: 45 DEGREE ENTRY BRANCH TAKE-OFF r MINIMUM r = W HOLLOW DOUBLE RADIUS TYPE TURNING VANES SEE NOTE 1 AIR SQUARE ELBOW SHOWN. PROVIDE ROUND ELBOW WHERE SHOWN ON PLANS. FLOW AIR FLOW DOUBLE RADIUS TURNING VANES MANUAL DAMPER 0.5W MINIMUM 45 O W 0.25 X W OR 4" MINIMUM W
