A galvanized pipe sleeve penetrates a drywall partition framed with metal studs and surfaced with gypsum board. The annular space around the pipe features a one-quarter inch gap filled with acoustical sealant and backer rod on both sides, with fiberglass insulation or firestopping material packed through the core at rated walls. A minimum twenty-two gauge sheet metal angle ring is secured to the sleeve to retain the assembly. Optional pipe insulation continues along the run, and escutcheon plates conceal exposed penetrations on one or both sides where required.
BACKER ROD SHEET METAL ANGLE RING (MIN. 22 GA.) SECURE TO SLEEVE. PIPE INSULATION (WHERE REQD) METAL STUD ONE OR BOTH SIDES WHERE ESCUTCHEON PLATE ON PIPING IS EXPOSED. GALVINIZED PIPE SLEEVE DRYWALL PARTITION PIPE 1/4" GAP AROUND PERIMETER FILLED WITH ACOUSTICAL SEALANT (TYP BOTH SIDES) FIBERGLASS INSULATION FIRESTOPPING MATERIAL AT RATED WALLS (TYP BOTH SIDES)
