An exhaust duct connects to an air device through a spin-in fitting equipped with a damper and a Young or equivalent type regulator for non-removable ceilings. A hard duct connector links the spin-in fitting to the air device duct boot, which terminates at the air device mounted flush within the ceiling assembly. A sizing table correlates neck sizes ranging from one hundred fifty to three hundred millimeters with corresponding flow rate ranges in liters per second.
AIR DEVICE SPIN-IN FITTING WITH DAMPER (PROVIDE YOUNG OR EQUIVALENT TYPE REGULATOR IN NON REMOVABLE CEILINGS) AIR DEVICE DUCT BOOT 150mm ø NECK SIZE 250mm ø 200mm ø 300mm ø DUCT HARD CONNECTOR CEILING 78-128 43-78 24-43 0-24 L/s RANGE EXHAUST DUCT
