A bellmouth transition fitting connects a rectangular duct to an acoustic housing with a forty-five degree sloped transition wall. Acoustic fill lines the interior space surrounding the sloped transition fitting. The fitting length L equals one quarter of the greatest duct dimension, maintaining a minimum length of six inches and a maximum length of twelve inches.
HOUSING DUCT DUCT HOUSING ACOUSTIC FILL (2) (2) 45° 45° NOTES: (1) L = 1/4 x (GREATEST DUCT DIMENSION), BUT NOT LESS THAN 6" AND NOT MORE THAN 12". L L
