Suspended VAV box support assembly utilizing either a 1 1/2" x 1 1/2" x 1/8" angle iron or a 1 5/8" x 1 5/8" 12-gauge strut channel spanning beneath the duct. The support member is hung from overhead by hanger rods secured with nuts and washers on both sides of the angle typically. Lateral stability is provided by 3/16" diameter aircraft cable sway bracing attached typically.
DUCT SEE PLANS FOR SIZES AND LOCATIONS HANGER RODS NUT & WASHER BOTH SIDES OF ANGLE (TYP.) 1 1/2"x 1 1/2"x 1/8" ANGLE IRON OR 1 5/8"x 1 5/8"x 12 GA. STRUT CHANNEL. 3/16" ∅ AIRCRAFT CABLE SWAY BRACING (TYP.) NOT TO SCALE NOT TO SCALE 1 VAV BOX SUPPORT DETAIL
