A variable refrigerant flow blower coil unit is suspended from the ceiling or a Unistrut mounting structure using neoprene vibration pads at the mounts. Flexible connectors tie the insulated supply duct and suction flange into the unit. Refrigerant liquid and gas lines as well as a condensate hose connect directly to the blower coil housing. A manufacturer-supplied filter section is integrated at the inlet and sized to accommodate a one-inch carbon filter for future application.
CONDENSATE CEILING OR UNI-STRUT MOUNTING STRUCTURE NEOPRENE VIBRATION PAD AT MOUNT FLEX CONNECTOR INSULATION SUPPLY DUCT VRF BLOWER COIL INSULATION LIQUID GAS VRF BLOWER COIL MANUFACTURER SUPPLIED FILTER SECTION 1. NOTE: FILTER SECTION SHALL BE CAPABLE OF FITTING 1" CARBON FILTER FOR FUTURE APPLICATION. SUCTION FLANGE FLEX CONNECTOR CONDENSATE LIQUID GAS CONDENSATE HOSE CONNECTION
