The assembly connects a supply air main duct to a VAV terminal unit requiring three straight duct diameters upstream of the inlet. The inlet duct size matches the valve inlet, and the downstream sheet metal duct must be a minimum of 48 inches long, lined with 1 inch thick, 1.5 lb/ft3 fiberglass coated with neoprene. Hot water coils are integrated into the duct run, and a control panel requires 36 inches of clear space maintained in front of the panel.
VAV - NOTICE: 1. MINIMUM 48" SHEET METAL DUCT LINED WITH 1" THICK, 1.5 LB/FT FIBERGLASS COATED WITH NEOPRENE. 2. CONTROL PANEL. (MAINTAIN 36" CLEARANCE IN FRONT OF PANEL) SEE NOTE '2' SUPPLY AIR MAIN DUCT THREE STRAIGHT DUCT DIAMETERS SEE NOTE '1' DUCT DIAMETERS THREE STRAIGHT HOT WATER COILS SUPPLY AIR MAIN DUCT INLET DUCT SIZE TO MATCH VALVE INLET ELEVATION PLAN VIEW
