Mechanical · M-9HJ3V

Pump Piping and Vibration Isolation Detail

Materials

Elements

Insulation Millwork / Casework Connections / Plates

About this detail

An inline pump mounts onto a concrete inertia base supported by spring isolators, with the motor positioned outside of any cover boxes. Piping connections include flexible pipe connectors, long-radius elbows, and base elbow supports as required. System accessories comprise typical shut-off valves, check valves, y-strainers with blow-off valves, thermometers, and pressure gauges. Removable insulation covers are specified for piping accessories requiring future access.
