A variable frequency drive attaches to two vertical Unistrut supports using factory-provided mounting holes at six locations. The Unistrut supports feature baseplates lagged into a wood sleeper with a minimum one-foot clearance above the roof surface. The sleeper is covered by a sheetmetal cap and fully integrated into the roofing materials and waterproofing provided by the general contractor.
BASEPLATE LAGGED INTO SLEEPER SHEETMETAL CAP ROOFING MATERIALS AND WATERPROOFING BY G.C. ROOFED IN SLEEPER BY G.C. UNISTRUT SUPPORT (TYP.2) VARIABLE FREQUENCY DRIVE ATTACH TO UNISTRUT USING FACTORY PROVIDED MOUNTING HOLES (TYP.6) 1' MIN ROOF
