Mechanical · M-92NF6

Seismic Fan and VAV Box Installation Detail

Materials

Elements

Floors / Slabs Bracing Connections / Plates

About this detail

An in-line or variable air volume box is suspended from the overhead structure using a minimum of two 1-inch, 20-gauge sheet metal hanger straps wrapped around the entire unit. The straps attach to the building structure and at all corners of the unit, extending out and up at a forty-five degree minimum angle. Accompanying notes specify seismic requirements for Seismic Category D per SMACNA, IBC, and ASCE 7, including weight and flexibility exemptions.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
