An inline fan is suspended from the structure above using vertical threaded rods equipped with typical vibration isolation springs. The fan unit connects on both sides to ductwork via flexible duct connections where applicable. Aircraft cables are installed at a forty-five-degree angle for typical lateral seismic or sway bracing. The attachment to the structure above secures the vertical hangers and lateral brace cables.
ISOLATION (TYP.) DUCT W/ FLEX CONNECTION WHERE APPLICABLE AIRCRAFT CABLE FOR LATERAL BRACING TYPICAL @ 45° ANGLE ATTACHMENT TO STRUCTURE ABOVE (TYP.)
