The relief fan connects to the plenum wall using a flexible connection to isolate vibration, paired with an adjacent control damper inside the plenum. The fan assembly is supported from the building structure on spring isolators as specified in the drawing notes.
PLENUM FLEXIBLE CONNECTION CONTROL DAMPER RELIEF FAN PLENUM WALL SUPPORT FAN FROM STRUCTURE ON SPRING ISOLATORS
