Insulated pipes rest on type 39 pipe saddles at least 18 inches long over pipe rollers and roller stands secured with bolts. The assembly is suspended by vertical hanger rods with locking nuts spaced a maximum of 42 inches center to center. Insulation is maintained with vapor barriers where specified, and all supports conform to MSS SP-58 and MSS SP-69 standards.
TO MAX. SPACING 42" VAPOR BARRIER INSULATION PIPE HANGER ROD PIPE SADDLE AT LEAST 18" LONG LOCKING NUT BOLT PIPE ROLLER TO SUPPORT ROLLER* STAND* INSULATION (NOT VAPOR BARRIER) NOTE: REFER TO 23 52 00, 23 64 26 AND 23 05 48.19 FOR ANCHORAGE, SUPPORT, AND SEISMIC BRACING DELEGATED DESIGN INFORMATION. SHALL CONFORM TO MSS SP-58 AND MSS SP-69, EXCEPT AS MODIFIED BY THESE SPECIFICATIONS. 1. TYPE 39 SADDLE
