An insulated pipe is suspended from a hanger rod secured by a support nut and locking nut threaded into a heavy-duty clevis hanger. The insulated pipe rests inside an eighteen-inch-long fourteen-gauge protective shield that wraps around the exterior insulation. The metal shield is banded directly to the insulation to prevent crushing from the clevis hanger.
HANGER ROD LOCKING NUT SUPPORT NUT INSULATION PIPE HEAVY DUTY CLEVIS HANGER 14 GAUGE SHIELD 18" LONG TO PROTECT INSULATION, BAND SHIELD TO INSULATION
