Multiple typical direct expansion pipes penetrate the faceplate of a base with a skirt mounted to the roof assembly, which is installed by the general contractor. Expanding foam seals the annular space around each pipe where it passes through the faceplate. A removable lid covers the top of the base assembly to allow access to the interior penetrations.
BASE WITH SKIRT FOR ROOFING RUN PIPE THROUGH FACEPLATE TYP DX PIPE EXPANDING FOAM AROUND PIPE REMOVABLE LID ROOFING BY G.C
