Insulated refrigerant pipes rest atop strut support channels secured by two-part pipe clamps. The channels are elevated on Dura-Block DB10-42 rooftop supports resting directly on a concrete roof surface. The DB10-42 blocks provide a one thousand pound capacity uniform distributed load rating. This assembly secures rooftop mechanical piping without penetrating the roof membrane.
1 2 4 3 DB10-42 1000# CAPACITY UNIFORM DISTRIBUTED LOAD 4. STRUT SUPPORT CHANNEL 3. INSULATED REFRIGERANT PIPE 2. TWO PART PIPE CLAMP 1. DURA-BLOCK DB10-42 NOTES: N.T.S. 9 RETURN AIR FLEXIBLE SOUND BOOT
