A grinder hood features a table surface with an integrated circular disc and slot connecting to a forty-five degree exhaust duct. A blast gate is installed along the vertical duct section to regulate airflow from overhead exhaust or to a dedicated dust collection system. Sizing and location of the overhead duct are coordinated per architectural and mechanical plans.
BLAST GATE DUCT DUCT FROM OVERHEAD PLANS FOR SIZE AND LOCATION. TABLE DISC SLOT 45° EXHAUST OR TO DEDICATED DUST COLLECTOR. SEE
