A cast iron or Schedule 40 pipe sleeve is cast into the concrete exterior wall below the finished grade. A service pipe passes through the sleeve, secured with a mechanical sleeve seal to ensure watertightness. The annular space is packed with insulation and caulked as required. Pipe insulation surrounds the interior run of the pipe, and the flange is located to allow proper clearance for the seals.
FINISHED FLOOR PIPE PIPE INSULATION PACK WITH INSULATION AND CAULK AS REQUIRED FINISHED GRADE CAST IRON OR SCH 4D PIPE SLEEVE CAST- IN-PLACE MECHANICAL SLEEVE SEAL EXTERIOR WALL 1'-10 5/32" LOCATE FLANGE TO ALLOW CLEARANCE TO SEALS
