The mechanical pump assembly mounts to an optional inertia base positioned over a three-and-a-half-inch concrete pad. A suction diffuser connects to the pump inlet alongside valving and pressure gauge connections. Valves mount as low as practical while maintaining required straight pipe lengths for balancing valves. The inertia base extends beneath the suction diffuser when specified, with grouting requirements per project specifications.
(2) (4) NOTE: (1) INERTIA BASE IF SPECIFIED, SHALL EXTEND UNDER SUCTION DIFFUSER. (2) MOUNT VALVES AS LOW AS PRACTICAL, WHILE MAINTAINING STRAIGHT PIPE LENGTH REQUIRED BY BALANCING VALVE IF PROVIDED. (3) REFER TO SPECIFICATION FOR GROUTING REQUIREMENT. (4) REFER TO SPECIFICATION SECTION 23 2118, PART 3 TO DETERMINE IF BALANCING VALVES ARE REQUIRED AND FOR STRAIGHT PIPE LENGTH WHEN BALANCING VALVES ARE REQUIRED. 3-1/2" CONCRETE PAD INERTIA BASE WHERE SPECIFIED SUCTION DIFFUSER (2)
