Piping layout and component connections for an air-cooled chiller system linked to a chilled water coil. The assembly features supply and return lines connected via unions, shut-off valves, and manual or automatic air vents for system purging. Pressure-independent control valves, thermometers, and pressure/temperature ports allow for flow regulation and diagnostic monitoring. Strainers with fine mesh screens protect the coil, while coil drain valves with threaded hose connections provide maintenance access.
CHS CHR (TYP) (TYP) (TYP) (TYP) (TYP) (TYP) 10 9 8 7 1 2 3 4 5 6 UNION SHUT-OFF VALVE MANUAL AIR VENT AUTOMATIC AIR VENT PRESSURE INDEPENDENT CONTROLVALVE EQUAL TO DANFOSS MODEL AB-QM THERMOMETER CHILLED WATER COIL COIL DRAIN VALVE WITH THREADED HOSE CONNECTION P/T PORT (PETES PLUG) STRAINER WITH FINE MESH SCREEN 1 2 3 4 5 6 7 8 9 10
