Rectangular and round branch ducts connect to main supply and return air ducts using forty-five degree low-loss take-off fittings. Each branch duct incorporates a manual balancing damper with a locking quadrant. Flexible duct connections are secured with mechanical clamps without using duct tape. All branch take-offs require low-loss fittings regardless of whether they are shown on the floor plan.
ALL BRANCH TAKE-OFFS SHALL HAVE A LOW LOSS FITTING WHETHER SHOWN ON THE FLOOR PLAN OR NOT. NOTE: LOCKING QUADRANT MANUAL BALANCING DAMPER WITH BRANCH DUCT MAIN RA. SA. RA. SA. "D" "D" 4 45° 45° ROUND BRANCH DUCT RECTANGULAR BRANCH DUCT FLEX DUCT MANUAL BALANCING LOCKING QUADRANT MAIN DUCT DAMPER WITH NOT USE CLAMP (DO DUCT TAPE)
