A 90-degree dual deflection register with 45-degree adjustable horizontal and vertical vanes connects to an 18-gauge sheet metal boot secured airtight to the main supply duct. A high efficiency take-off feeds the boot, incorporating an opposed blade damper with a two-inch minimum clearance. The round supply duct is sized per plan, directing airflow through the assembly.
90° DUAL DEFLECTION REGISTER WITH 45° ADJUSTABLE VANES HORIZONTAL AND VERTICAL ROUND SUPPLY DUCT SEE PLAN FOR SIZE 18 GA. BOOT SECURE TO DUCT AIR TIGHT AIR FLOW 45° 2" MIN. O.B.D. HIGH EFFICIENCY TAKE-OFF
