A factory-supplied mounting bracket is anchored to wood framing using four-inch by six-inch timber blocking typical for two locations. The bracket is fastened with three-eighths-inch by two-and-one-half-inch lag screws typical for four locations. An A34 clip is provided at the top and bottom on both ends to secure the blocking assembly.
4"x6" BLOCKING (TYP FOR 2) 3/8"x2 1/2" LAG SCREW (TYP FOR 4) A34 CLIP AT TOP & BOTTOM BOTH ENDS FACTORY SUPPLIED MOUNTING BRACKET
