A natural gas pipe is suspended from an open web steel bar joist using a threaded rod and a clevis hanger assembly. The threaded rod attaches to the top chord of the bar joist using a beam clamp or approved method. The gas pipe is supported by a clevis hanger and positioned above the bottom chord of the joist typically. An oversized clamp is provided to allow for thermal movement in the hanger. Alternatively, a U-clamp is bolted directly to the bottom chord of the joist as shown in the elevation view.
U-CLAMP TO BE BOLTED TO BOTTOM CHORD OF JOIST BAR JOIST GAS PIPE PROVIDE OVERSIZED CLAMP TO ALLOW FOR THERMAL MOVEMENT IN HANGER CLEVIS HANGER ATTACH ROD TO TOP CHORD OF BAR JOIST USING BEAM CLAMP OR APPROVED METHOD GAS PIPE TO BE HUNG ABOVE BOTTOM CHORD OF JOIST (TYP) BAR JOIST
