Plan view and elevation view of air handling unit AHU-123. The elevation view indicates an overall length of 182 inches and a height of 46 inches, with internal components shown with dashed lines. Numbered callouts 1 through 11 and lettered callouts A through D reference specific components and connections throughout the unit.
