A seismic cable bracing system for mechanical equipment is anchored with threaded rods and strut channels. The assembly features an M.W. Sausse' seismic cable bracing equipment kit including upper and lower SLH-34 brackets, SLW-1 slotted washers, rod stiffener clamps, and 1/8-inch 7x19 galvanized aircraft cables secured with cable clamps. The cables are installed hand-tight without slack, utilizing anchor bolts provided by the contractor. Optional rod stiffeners may be included depending on installation requirements.
( ) CABLE - 1/8" - 10 FT. ( ) CABLE CLAMPS - 1/8" 04 16 ( ) UPPER SLOTTED WASHER -SLW-1 ( ) LOWER SLOTTED WASHER -SLW-1 ( ) UPPER BRACKET - SLH-34 ( ) LOWER BRACKET - SLH-34 M.W. SAUSSE' SEISMIC CABLE BRACING EQUIPMENT KIT NO: 18C4-12SLH-34 EQUIPMENT BRACING KIT: 18C4-12SLH-34 ( ) ROD STIFFENER CLAMLPS - RS-1 04 04 04 04 08 NOTE: 1) CABLE IS 7 X 19 GALVANIZED AIRCRAFT CABLE. 4) ROD STIFFENER MAY BE REQUIRED. SEE DETAIL - 4 3) FOR CABLE ANCHORAGE, SEE DETAIL - 3 2) CABLES TO BE INSTALLED HAND TAUT W/O SLACK. THREADED ROD (BY CONTRACTOR) EQUIPMENT 1 1 PLAN VIEW TYPICAL STRUT CHANNEL (BY CONTRACTOR) ROD STIFFENER CLAMPS-RS-1 LOWER SLOTTED WASHER-SLW-1 CABLE CLAMPS AIRCRAFT CABLE UPPER BRACKET-SLH-34 ANCHOR BOLT (BY CONTRACTOR) LOWER BRACKET-SLH-34 1 1 UPPER SLOTTED WASHER-SLW-1
