Insulated refrigerant pipes are supported on a roof surface using Dura-Block DB10-42 rooftop supports with a one thousand pound uniform distributed load capacity. Two-part pipe clamps secure each pipe to a strut support channel resting directly on the Dura-Block supports.
1 2 4 3 DB10-42 1000# CAPACITY UNIFORM DISTRIBUTED LOAD 4. STRUT SUPPORT CHANNEL 3. INSULATED REFRIGERANT PIPE 2. TWO PART PIPE CLAMP 1. DURA-BLOCK DB10-42 NOTES: N.T.S. 10 RETURN AIR FLEXIBLE SOUND BOOT
