A pipe or duct is supported by a pipe clamp or angle ring resting on structural angles sized per load but no smaller than 1-1/2 inches by 1-1/2 inches by 1/4 inch. A diagonal angle brace ties the horizontal support back to a vertical mounting angle anchored directly to the masonry wall. Stainless steel expansion anchors fasten the vertical angle to the masonry substrate.
PIPE OR DUCT SIDE VIEW ANGLES TO BE SIZED PER LOAD, BUT NOT SMALLER THAN 1-1/2" x 1-1/2" x 1/4" PIPE CLAMP OR ANGLE RING SS EXPANSION ANCHORS TO MASONRY WALL. B
