Mechanical · M-36DWF

Laboratory Exhaust Fan Mounting Detail

Materials

Elements

Walls Stairs Roofs Waterproofing / Flashing Connections / Plates

About this detail

A laboratory exhaust fan unit rests on a concrete pad provided by the general contractor, with waterproofing and roofing materials installed at the base. The unit features a structural mounting arrangement per the structural submittal, accompanied by a one-inch condensate connection, sheet metal flashing, and an architectural screen wall located seventeen feet away. Internal and attached components include heat recovery coils linked to piping per sheet M1.6.02, a thirty-six by sixty inch bypass with manual and control dampers, eyebrow hoods with wall mounting system, and five sixty-six inch diameter connections to laboratory exhaust fans. Additional elements comprise a MERV-8 filter bank, factory-provided lighting, control dampers, ninety-eight by two hundred ten inch exhaust riser connections, and a factory-provided light switch wired by the electrical contractor.
