Packaged air conditioning equipment sets on a manufacturer-supplied roof curb that is leveled by the general contractor and anchored to a concrete roof per structural and seismic submittals. The curb maintains a minimum height of eight inches above the finished roof. Roofing and counter flashing are installed by the general contractor with unit attachment secured directly to the factory curb.
8" MIN. ABOVE FINISHED ROOF PACKAGED AC EQUIPMENT SET ON MANUFACTURER'S ROOF CURB UNIT ATTACHMENT TO FACTORY CURB PER STRUCTURAL SUBMITTAL MANUFACTURER SUPPLIED ROOF CURB, LEVELED BY G.C. ROOFING BY G.C. SEE SEISMIC SUBMITTAL FOR ANCHORAGE TO CONCRETE ROOF COUNTER FLASHING AS REQUIRED AC 1
