An elevated roof-mounted pipe support rack features longitudinal angle iron bracing installed on both sides of the support structure in opposite directions. The pipe rack includes vertical supports spaced at a maximum of eight feet apart carrying horizontal pipes across the structural frame.
± 8FT MAX. ANGLE IRON BRACING NOTE: 1. PROVIDE LONGITUDINAL PIPE BRACING ON BOTH SIDES OF THE PIPE RACK IN OPPOSITE DIRECTION. 4 ELEVATION A-A, PIPE SUPPORT ON ROOF
