A four-inch floor cleanout plate, specified as Jay R. Smith Fig. 4106 or equal, is set flush within the finished floor and concrete slab assembly. The cleanout body connects to the drainage piping below, with the joint sealed using lead and oakum caulking packed all around.
CLEANOUT FLOOR PLATE 4" RIM JAY R. SMITH FIG. 4106 OR EQUAL CAULK W/ LEAD & OAKUM ALL AROUND
