Boiler B-1 is outfitted with a 60 pounds per square inch gauge American Society of Mechanical Engineers pressure safety relief valve and an automatic gas valve assembly connected to the gas main with a 6-inch dirt leg and a 2-inch union, while the pressure regulator vent extends to the exterior. A 2-gallon shot feeder with a funnel ties into the system alongside expansion tank ET-1 and chilled water supply piping CWS. High capacity auto air vent AS-1 is installed on an 8-inch main with isolating valves, and pumps P-2 and P-3 handle circulation with variable frequency drive controls. A full-size pipe runs from the relief and drain lines directly to the floor drain.
P-3 PIPE FULL SIZE TO FLOOR DRAIN 60 PSIG ASME PRESSURE SAFETY RELIEF VALVE (TYP) AUTO. GAS VALVES GAS PIPING FINAL CONNECTION BY PLUMBING CONTRACTOR 6" DIRT LEG 2" UNION TO GAS MAIN EXTEND PRESS. REG. VENT TO EXTERIOR B-1 2" 2" 2 GALLON SHOT FEEDER WITH FUNNEL 3/4" CWS AS-1 ET-1 1" 4" P-2 I HIGH CAPACITY AUTO AIR VENT 8" I 2" 3" 30" VFD 4"
