A natural gas utility meter set receives a 2 PSI gas supply routed through the building wall, featuring a sleeve and caulked penetration with a shut-off directly inside the structure. The exterior assembly includes a flexible connection, a seismic gas shut-off valve, a lockable shut-off valve, and pipe flange supports anchored to a concrete base. A gas vent extends upward and terminates twelve feet above finished floor with an 180-degree fitting and screened opening, accompanied by a pulse meter connection to the energy management system. All gas supports derive from the ground rather than the building, with exterior piping painted per specifications.
