An upblast exhaust fan mounts directly to a prefabricated insulated roof curb seated over a roof decking or slab opening. A gasket or sealant is placed between the fan base and the curb, supplemented by integral counterflashing secured to the curb. A motorized damper sits within the throat below the fan, while a birdscreen and disconnect switch are integrated into the fan unit. A one-inch clear opening is maintained around the duct assembly to allow for movement, and roofing materials tie into the curb base per architectural drawings.
SECURE FAN TO CURB GASKET OR SEALANT COUNTERFLASHING INTEGRAL TO FAN PREFABRICATED INSULATED ROOF CURB ROOF DECKING / SLAB ROOFING MATERIAL REFER TO ARCH DRAWINGS FOR ROOFING DETAILS PROVIDE 1" / 25MM CLEAR OPENING AROUND DUCT ASSEMBLY TO ALLOW FOR MOVEMENT NOTES: DUCT MOTORIZED DAMPER FAN DISCONNECT SWITCH BIRDSCREEN
